Picture of three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC
Picture of three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC
Picture of three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC
Picture of three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC
SKU:

SSP3A250B7RT

three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC

Old price: $499.95 INC GST
$474.95 INC GST
Available for Shipping : 12-Aug-2025
Product Selector
three phase relay, Harmony Solid State Relays, 50A, panel mount, random switching, thermal pad, input 18 to 36V AC, output 48 to 530V AC
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Image of product in real life situation
Instruction sheet
Declaration of conformity
Circularity Profile
Product Page Link
Product Data Sheet
This Harmony SSP solid state panel mount 3-phase relay is rated 50A, is controlled with a 18V to 36V AC input, has a rated load voltage of 48V to 530V AC with random voltage switching, ideal for inductive loads. It has a visual indicator showing the status of its input and a alarm output enabling a quick response to unexpected events. It also has a test button for easy debugging, testing and commissioning. It is also silent and reliable thanks to the absence of moving contacts. 0 0 0 0 0 0 0 0 0 0 0 0

Products specifications

Attribute name Attribute value
Main
Device short name SSP
[Uc] control circuit voltage 18...36 V
[In] rated current 50 A
Provided equipment thermal interface
Solid state output type random voltage switching
Network number of phases 3 phases
Product or component type solid state relay up to 50 A
Output switching mode random voltage switching
Mounting support panel
Range of product Harmony Solid State Relays
Connections - terminals screw connectors
Complementary
Motor power kW 6.47 kW at 40-40 °C 530 V AC, 5.55 kW at 40-40 °C 480 V AC, 2.22 kW at 40-40 °C 240 V AC, 1.11 kW at 40-40 °C 120 V AC
Depth 35.4 mm
Input current limits 15-20 mA
Width 101.3 mm
Capacitance unbalance 8 pF for input/output
Maximum switching voltage 2 V AC turn-off
DV/dt 500 V/µs off-state at maximum voltage
Absolute maximum voltage 1200 V
Device presentation complete product
Control type without test button
IP degree of protection IP20
Maximum leakage current 3 mA off-state
Minimum switching voltage 18 V AC turn-on
Net weight 0.24 kg
Local signalling LED, green for input
Load current 0.1-50 A
Surge current 150 A for 1 s, 750 A for 16.6 ms, 715 A for 20 ms
Response time 0.1 ms (turn-on), 30 ms (turn-off)
Dielectric strength 4 kV AC for input or output to case, 4 kV AC for input/output
Connections - terminals screw terminals: 1 x 1.5...1 x 10 mm², (AWG 16...AWG 8) for output, screw terminals: 1 x 0.2...1 x 2.5 mm², (AWG 24...AWG 14) for input
Maximum voltage drop <1.35 V on-state
Maximum I²t for fusing 2320 A².s for 8.3 ms at 60 Hz, 2520 A².s for 10 ms at 50 Hz
Thermal resitance 0.12 °C/W
Insulation resistance >= 1000 MOhm at 500 V DC
Tightening torque 1.7...2.2 N.m for output, 0.9...1.1 N.m for input
Motor power hp 8.8 hp 40 °C 530 V AC, 7.5 hp 40 °C 480 V AC, 3 hp 40 °C 240 V AC, 1.5 hp 40 °C 120 V AC
Height 79.7 mm
Cos phi 0.5-0.5 (with maximum load)
Environment
Overvoltage category III
Ambient air temperature for storage -40-125 °C
Flame retardance V0 conforming to UL 94
Marking CE
Pollution degree 2
Standards IEC 61000, IEC 60950-1, IEC 62314
Ambient air temperature for operation -40-80 °C
Product certifications CSA, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4 cm
Package 1 Width 8.5 cm
Package 1 Length 12 cm
Package 1 Weight 274 g
Unit Type of Package 2 2
Number of Units in Package 2 27
Package 2 Height 15 cm
Package 2 Width 30 cm
Package 2 Length 40 cm
Package 2 Weight 7.793 kg
