SKU:

DF2FN10

NFC cartridge fuses, TeSys GS, cylindrical, 22mm x 58mm, fuse type gG, 690VAC, 10A, without striker, set of 10 parts

Old price: $136.40 INC GST
$120.03 INC GST
Available for Shipping : 23-Jul-2025
NFC cartridge fuses, TeSys GS, cylindrical, 22mm x 58mm, fuse type gG, 690VAC, 10A, without striker, set of 10 parts
  • TeSys Power (TeSys GS) switch-disconnector fuses are NFC/DIN fuse compatible
  • Enhanced isolation between poles
  • On-load making/breaking with double break isolation of the power circuit
  • Current range from 32A up to 1250A
  • NFC cylindrical aM fuse type 22mm x 58mm
  • Maximum fuse rated voltage is 690VAC
Manufacturer: Schneider Electric
This is a NFC fuse cartridge for TeSys GS switch-disconnector fuses devices. It is a gG fuse-link that protects against thermal overloads and magnetic over currents, used in standard applications. Its current rating is 10 A and the maximum rated voltage is 690 VAC. It is a cylindrical fuse (NFC type), the dimensions are 22mm x 58mm. It has no striker to indicate when the fuse is blown. This fuse is sold by set of 10 parts.

Products specifications

Attribute name Attribute value
Main
Device short name DF2
Quantity per set set of 10
Fuse type NFC
Product or component type cartridge fuse
[In] rated current 10 A 690 V
Range of product TeSys fuse-disconnector
[Ue] rated operational voltage 690 V AC
Fuse size 22 x 58 mm
Complementary
Compatibility code DF2
Fuse curve gG
Net weight 0.045 kg
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 2.5 cm
Package 1 Width 11.3 cm
Package 1 Length 12.0 cm
Package 1 Weight 50.0 g
Unit Type of Package 2 2
Number of Units in Package 2 10
Package 2 Height 2.5 cm
Package 2 Width 11.3 cm
Package 2 Length 12.0 cm
Package 2 Weight 506.0 g
Unit Type of Package 3 3
Number of Units in Package 3 50
Package 3 Height 15.0 cm
Package 3 Width 15.0 cm
Package 3 Length 40.0 cm
Package 3 Weight 2.728 kg
