SKU:

BMXAMO0210

analog isolated high level output module, Modicon X80, 2 outputs, 0 to 20mA, 4 to 20mA, 10V positive or negative

$1,383.91 INC GST

Qty:

Available for Shipping : 24-Jul-2025

Product Selector

analog isolated high level output module, Modicon X80, 2 outputs, 0 to 20mA, 4 to 20mA, 10V positive or negative

Be the first to review this product

Manufacturer: Schneider Electric

Catalog

Declaration of conformity

User guide

Circularity Profile

CAD

Environmental Disclosure

Product Page Link

Product Data Sheet

This analog output module is part of the Modicon X80 modules. It has 2 isolated high level outputs (15 bits + sign). It offers different ranges of voltage or current for each of the outputs depending on configuration choice. It occupies a single slot on the rack and it has a case which provides IP 20 protection of the electronics.

Products specifications

Attribute name	Attribute value
Main
Input output isolation	isolated
Electrical connection	20 ways 1 connector
Product or component type	analog output module
Range of product	Modicon X80
Complementary
Conversion time	<= 1 ms
Analogue output resolution	15 bits + sign
Operating altitude	2000...5000 m with derating factor, 0...2000 m
Detection type	short circuit +/- 10 V, open circuit 4...20 mA, open circuit 0...20 mA
Load impedance ohmic	>= 1000 Ohm +/- 10 V, <= 600 Ohm 4...20 mA, <= 600 Ohm 0...20 mA
Power consumption in W	0.48 W 3.3 V DC maximum, 0.35 W 3.3 V DC typical, 2.8 W 24 V DC maximum, 2.1 W 24 V DC typical
Analogue output number	2
Isolation voltage	750 V DC between channels, 1400 V DC between channels and bus, 1400 V DC between channels and ground
Net weight	0.144 kg
Minimum crosstalk attenuation	90 dB
Current consumption	110 mA at 24 V DC, 150 mA at 3.3 V DC
Supply	internal power supply via rack
Output level	high level
Common mode rejection	100 dB
Analogue output type	voltage: +/- 10 V, current: 4...20 mA, current: 0...20 mA
Recalibration	factory calibrated
Temperature drift	30 ppm/°C
Status LED	1 LED (red) I/O, 1 LED (red) ERR, 1 LED per channel (green) channel diagnostic, 1 LED (green) RUN
Maximum conversion value	0...24 mA 4...20 mA, 0...24 mA 0...20 mA, +/- 11.25 V +/- 10 V
Measurement error	0.1 % of full scale 25 °C, <= 0.2 % of full scale 0...60 °C
Fallback mode	configurable, predefined
MTBF reliability	1300000 H
Environment
IP degree of protection	IP20
Relative humidity	5-95 % at 55-55 °C without condensation
Ambient air temperature for storage	-40-85 °C
Directives	2014/30/EU - electromagnetic compatibility, 2014/35/EU - low voltage directive
Vibration resistance	3 gn
Shock resistance	30 gn
Standards	CSA C22.2 No 61010-2-201, UL 61010-2-201, EN/IEC 61131-2, EN/IEC 61010-2-201
Ambient air temperature for operation	0-60 °C
Product certifications	UL, Merchant Navy, EAC, CSA, RCM, CE
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	5.500 cm
Package 1 Width	11.000 cm
Package 1 Length	11.500 cm
Package 1 Weight	173.000 g
Unit Type of Package 2	2
Number of Units in Package 2	15
Package 2 Height	15.000 cm
Package 2 Width	30.000 cm
Package 2 Length	40.000 cm
Package 2 Weight	2.901 kg
