Picture of Manual overload reset push button, Harmony XB5, pushbutton Ø22 mm for 17...120 mm actuation distance
SKU:

XB5AA801

Manual overload reset push button, Harmony XB5, pushbutton Ø22 mm for 17...120 mm actuation distance

Old price: $53.35 INC GST
$41.61 INC GST
Available for Shipping : 27-Aug-2025
Product Selector
Manual overload reset push button, Harmony XB5, pushbutton Ø22 mm for 17...120 mm actuation distance
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Declaration of conformity
Catalog
Instruction sheet
Circularity Profile
Product Page Link
Product Data Sheet
This Harmony XB5, manual overload reset pushbutton without cap has an actuation distance from 17mm to 120mm. This complete manual overload reset pushbutton is supplied without cap for customization use with your desired machine operations. It provides a robust and precise control when it is required to reset your machines and processes. It is easily installed into standard 22mm diameter panel cut-outs. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation.

Products specifications

Attribute name Attribute value
Main
Device short name XB5
Operator profile without cap
Bezel material dark grey plastic
Device presentation complete product
Head type standard
Fixing collar material plastic
Shape of signaling unit head round
Product or component type manual overload reset push-button
Mounting diameter 22 mm
Activating distance 17-120 mm
Range of product Harmony XB5
Operator additional information without cap
Complementary
Depth 120 mm
Width 29 mm
Customizable no, 0
Compatibility code XB5
Mechanical durability 5000000 cycles
Resistance to high pressure washer 7000000 Pa at 55 °C, distance : 0.1 m
Net weight 0.027 kg
Height 29 mm
Environment
Protective treatment TH
Electrical shock protection class class II conforming to IEC 60536
NEMA degree of protection NEMA 4X
Ambient air temperature for storage -40-70 °C
IP degree of protection IP66 conforming to IEC 60529
Standards EN/IEC 60947-1
Ambient air temperature for operation -40-70 °C
IK degree of protection IK03 conforming to IEC 50102
Product certifications UL listed
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 4.200 cm
Package 1 Width 5.300 cm
Package 1 Length 12.800 cm
Package 1 Weight 36.800 g
Unit Type of Package 2 2
Number of Units in Package 2 60
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 2.600 kg
Unit Type of Package 3 3
Number of Units in Package 3 960
Package 3 Height 75.000 cm
Package 3 Width 80.000 cm
Package 3 Length 120.000 cm
Package 3 Weight 61.600 kg
