Picture of discrete output module Modicon Premium - 16 O solid state
SKU:

TSXDSY16S4

discrete output module Modicon Premium - 16 O solid state

$4,713.01 INC GST
Availability: Please contact our sales team on 1300 724 622.
discrete output module Modicon Premium - 16 O solid state
Be the first to review this product
Manufacturer: Schneider Electric
Catalog
Instruction sheet
Declaration of conformity
Product Page Link
Product Data Sheet

Products specifications

Attribute name Attribute value
Main
Discrete output number 16
Discrete output voltage 24...120 V AC conforming to EN/IEC 61131-2 20...132 V
Product or component type discrete output module
Range of product Modicon Premium Automation platform
Discrete output type triac not protected
Complementary
Module format standard
Short-circuit protection 10 A, non interchangeable fireproof protection
Net weight 0.38 kg
Response time < 10 ms (deactivation), < 10 ms (activation)
Output overvoltage protection Ge-Mov
Marking CE
Output overload protection 10 A, non interchangeable fireproof protection
Current consumption 220 mA at 5 V DC
Insulation resistance > 10 MOhm 500 V
Electrical connection screw terminal block
Current per channel 1 A
Maximum current per module 12 A
Power dissipation (0.85 W + 1 W x No of outputs x current per module)
Environment
Operating altitude 0...2000 m
IP degree of protection IP20
Protective treatment TC
Relative humidity 5-95 % without condensation for storage, 10-95 % without condensation for operation
Ambient air temperature for storage -25-70 °C
Dielectric strength 2000 V 50/60 Hz 60 s
Pollution degree 2
Standards 92/31/EEC, CSA C22.2 No 213 Class I Division 2 Group C, CSA C22.2 No 213 Class I Division 2 Group D, CSA C22.2 No 213 Class I Division 2 Group A, CSA C22.2 No 213 Class I Division 2 Group B, UL 508, IEC 61131-2, 89/336/EEC, CSA C22.2 No 142, 93/68/EEC, 73/23/EEC
Ambient air temperature for operation 0-60 °C
Product certifications RINA, DNV, GL, RMRS, ABS, LR, BV
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.5 cm
Package 1 Width 18.0 cm
Package 1 Length 26.0 cm
Package 1 Weight 558.0 g
