Picture of Discrete input module, Modicon TM5, digital 4I, 100 to 240 V AC, 2 wires
SKU:

TM5SDI4A

Discrete input module, Modicon TM5, digital 4I, 100 to 240 V AC, 2 wires

Old price: $326.70 INC GST
$310.36 INC GST
Available for Shipping : 11-Aug-2025
Product Selector
Discrete input module, Modicon TM5, digital 4I, 100 to 240 V AC, 2 wires
Be the first to review this product
Manufacturer: Schneider Electric
Catalog
Circularity Profile
Instruction sheet
Environmental Disclosure
User guide
Declaration of conformity
Product Page Link
Product Data Sheet
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. The digital output module provides 4 multi-voltage inputs 100/240 V AC. It provides a discrete input voltage of 100 to 240V AC, an input current consumption of 34mA at 5V DC bus. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an isolation between channel and bus at 2500V AC for 1min. It is furnished with 3 wires for electrical connection. It is an IP20 rated product. Its housing colour is black.It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.

Products specifications

Attribute name Attribute value
Main
Range of product Modicon TM5
Discrete input number 4
Product or component type discrete input module
Discrete input voltage 100...240 V
Complementary
Product compatibility PacDrive LMC Eco, motion controller, PacDrive LMC Pro 2, logic controller, PacDrive LMC Pro
Isolation 2500 V AC insulation between channel and bus for 1 minute, no insulation between channels
Colour black
Maximum power dissipation in W 1.08 W
Input voltage limits 100...240 V
Marking CE
Input filtering <= 40 ms hardware from state 0 to state 1, <= 30 ms hardware from state 1 to state 0, <= 25 ms configurable by software
Range compatibility PacDrive LMC motion controller, Modicon LMC058, Modicon M258
Local signalling 4 LEDs green for input status, 1 LED red for power supply, 1 LED green for power supply
Current consumption 34 mA at 5 V DC bus
Net weight 0.025 kg
Electrical connection 2 wires
Discrete input voltage type AC
Discrete input current 5-11 mA
Environment
Relative humidity 5-95 % without condensation
Ambient air temperature for storage -40-70 °C
Pollution degree 2 conforming to IEC 60664
IP degree of protection IP20 conforming to IEC 61131-2
Ambient air temperature for operation -10-50 °C (vertical installation), -10-60 °C with derating factor (horizontal installation), -10-55 °C without derating (horizontal installation)
Electromagnetic compatibility conducted and radiated emissions conforming to CISPR 11, conducted RF disturbances conforming to IEC 61000-4-6, 1.2/50 µs shock waves immunity test, 1 kV common mode conforming to IEC 61000-4-5, 1.2/50 µs shock waves immunity test, 0.5 kV differential mode conforming to IEC 61000-4-5, electrical fast transient/burst immunity test, 2 kV power lines conforming to IEC 61000-4-4, electrical fast transient/burst immunity test, 1 kV shielded cable conforming to IEC 61000-4-4, electrical fast transient/burst immunity test, 1 kV I/O conforming to IEC 61000-4-4, susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz conforming to IEC 61000-4-3, susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz conforming to IEC 61000-4-3, electrostatic discharge immunity test, 8 kV in air conforming to IEC 61000-4-2, electrostatic discharge immunity test, 4 kV on contact conforming to IEC 61000-4-2
Operating altitude 0...2000 m
Shock resistance 15 gn for 11 ms
Vibration resistance 3.5 mm at 5-8.4 Hz on DIN rail, 1 gn at 8.4-150 Hz on DIN rail
Storage altitude 0-3000 m
Standards CSA C22.2 No 213, IEC 61131-2, CSA C22.2 No 142, UL 508
Product certifications C-Tick, GOST-R, CSA, cULus
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 1.900 cm
Package 1 Width 5.900 cm
Package 1 Length 10.400 cm
Package 1 Weight 40.000 g
Unit Type of Package 2 2
Number of Units in Package 2 97
Package 2 Height 15.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 4.214 kg
