Picture of MF40 Butterfly Valve Actuator, 3-Wire Floating, 24Vac, 40Nm, Non-spring Return, IP54
SKU:

MF40-24F

MF40 Butterfly Valve Actuator, 3-Wire Floating, 24Vac, 40Nm, Non-spring Return, IP54

$1,530.65 INC GST
Available for Shipping : 28-Jul-2025
MF40 Butterfly Valve Actuator, 3-Wire Floating, 24Vac, 40Nm, Non-spring Return, IP54
  • Drives VF208W Valves: DN125…200
  • 24 Vac/dc Supply Voltage
  • Simple mounting, 2 hex bolts on mounting flange
  • No linkage kit or special tools required
  • Optional MD-S1 or MD-S2 Aux Switch for field installation
Be the first to review this product
Manufacturer: Schneider Electric
Catalog
Declaration of conformity
Instruction sheet
Product Page Link
Product Data Sheet
The MF4 is a robust reliable actuator for the control of the VF28W butterfly valves. The actuator mount the valve without linkage kits and connect using terminal blocks to simplify and reduce installation time. Auxiliary switch is available as an accessory. Power supply: 24 Vac/Vdc. On-Off/3P Control Signal. Torque: 4 Nm. Suitable for DN125…2. Operating time: 15 sec.

Products specifications

Attribute name Attribute value
Main
Switch function 2 SPDT (optional)
Hold-in power consumption in W 2-2 W
IP degree of protection IP54
[Us] rated supply voltage 24 V AC/DC
Electrical insulation class class III
Product destination butterfly valves
Control type electrically operated
Product or component type actuator
Power consumption in VA 6 VA AC
Targeted region Australia., Asia Pacific., Europe
Power consumption in W 4 W
Actuator rotary
Ambient air temperature for operation 0-50 °C
Tightening torque 40 N.m, 354 lb.in
Power loss return stay in place
Actuator model MF40-24F T54 00
Control signal floating, 2-position (on/off)
Leads and connections terminal block
Actuator type electric
Actuator product series MF40
Position indicator Stroke indicator on bracket
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 29.8 cm
Package 1 Width 19.6 cm
Package 1 Length 15.2 cm
Package 1 Weight 2.46 kg
