Picture of circuit breaker EasyPact CVS160B, 25kA at 415VAC, 125A rating thermal magnetic TM-D trip unit, 4P 4d
SKU:

LV516322

circuit breaker EasyPact CVS160B, 25kA at 415VAC, 125A rating thermal magnetic TM-D trip unit, 4P 4d

$891.77 INC GST
Available for Shipping : 12-Aug-2025
Product Selector
circuit breaker EasyPact CVS160B, 25kA at 415VAC, 125A rating thermal magnetic TM-D trip unit, 4P 4d
  • Good performance and cost-saving functionality for small and medium-sized buildings protection
  • Excellent breaking capacity ensures circuit safety
  • Safe to use: embeds thermal-magnetic trip unit providing adjustable thermal overload& fixed magnetic protection
  • Unique common accessories help standardisation of components
  • Compliant with multiple international standards
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Instruction sheet
Circularity Profile
Catalog
CAD
Product Page Link
Product Data Sheet
EasyPact CVS160B is a 4 poles 4d fixed circuit breaker with a high level of performance and cost-saving functionality. It is an optimal choice for small and medium-sized buildings protection applications. The breaking capacity (Icu) is 25kA rms at 415VAC 50/60Hz. The operational voltage is 440VAC 50/60Hz. This product embeds a 125A rating thermal-magnetic trip unit (TMD). TMD trip unit provides an adjustable thermal overload protection and a fixed magnetic protection. This 4 poles version (140mm x 161mm x 86mm) comes with a variety of optional functions and accessories. EasyPact CVS160B is compliant with international standards (IEC 60947, CCC, EAC). It can be installed in class II insulation switchboards as it is a class II front face device (IEC 60664-1).

Products specifications

Attribute name Attribute value
Main
Device short name CVS160B
Device application distribution
Protection type overload protection (thermal), short-circuit protection (magnetic)
Trip unit rating 125-125 A at 40 °C
Breaking capacity 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2, 25 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 40 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2
Range EasyPact
Protected poles description 4D
Earth-leakage protection without
Range of product EasyPact CVS100...250
Trip unit name TM-D
Trip unit technology thermal-magnetic
Poles description 4P
Utilisation category category A
Product name EasyPact CVS
Product or component type circuit breaker
Network type AC
[In] rated current 125 A at 40 °C
Complementary
[Uimp] rated impulse withstand voltage 8 kV conforming to EN/IEC 60947-2
Compatibility code CVS160
Mechanical durability 25000 cycles
Electrical durability 12000 cycles 415 V In conforming to IEC 60947-2
Mounting mode fixed
Upside connection front
Long time pick-up adjustment type Ir adjustable
Long time pick-up adjustment range 0.7...1 x In
Neutral protection setting 1 x Ir (4D)
Control type toggle
Downside connection front
Connection pitch 35 mm
Height 161 mm
[Ics] rated service breaking capacity 40 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2, 25 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2, 15 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2
Depth 86 mm
Width 140 mm
Neutral position left
Net weight 1.9 kg
Instantaneous pick-up adjustment type Ii fixed
Long time delay adjustment type fixed
Instantaneous pick-up adjustment range 1250 A
Breaking capacity code B
Thermal protection adjustment range 87.5-125 A
Mounting support backplate
Contact position indicator yes
Connections - terminals screw connection
Network frequency 50/60 Hz
Environment
Ambient air temperature for storage -50-85 °C
Pollution degree 3 conforming to IEC 60664-1
IP degree of protection IP40
Ambient air temperature for operation -25-70 °C
Electrical shock protection class class II
Standards IEC 60947-2, EN 60947-2
Product certifications IEC, GOST
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 14.000 cm
Package 1 Width 15.000 cm
Package 1 Length 19.500 cm
Package 1 Weight 2.257 kg
Unit Type of Package 2 2
Number of Units in Package 2 9
Package 2 Height 30.000 cm
Package 2 Width 40.000 cm
Package 2 Length 60.000 cm
Package 2 Weight 21.196 kg
