Picture of circuit breaker, EasyPact CVS100N, 50kA at 415VAC, 32A, TM-D trip unit, 3P3d
SKU:

LV510472

circuit breaker, EasyPact CVS100N, 50kA at 415VAC, 32A, TM-D trip unit, 3P3d

$623.15 INC GST
Available for Shipping : 24-Jul-2025
Product Selector
circuit breaker, EasyPact CVS100N, 50kA at 415VAC, 32A, TM-D trip unit, 3P3d
  • Excellent breaking capacity ensures circuit safety
  • Certified for operation in heavily polluted environment
  • Easy installation without downgrading switchboard insulation
  • Very high proteciton degree, also for extended rotary handle
  • Unique common accessories help standardisation of components
Be the first to review this product
Manufacturer: Schneider Electric
Environmental Disclosure
Instruction sheet
Catalog
Product Page Link
Product Data Sheet
This device is a rated current 32A circuit breaker from EasyPact CVS250N. The rated breaking capacity(Ics) is 50kA at 415VAC,and complete range with Ics=100%Icu. The version of breaker is 3poles frame with detection on 3poles, also accompanied TM-D trip unit for thermal-magnetic protection. It is conformed to standard IEC60947-2 for circuit breakers part. This device is certified for operation in pollution degree III environment as defined IEC60947-1& IEC60664-1, and respected for RoHs requirement as european environment directive EC/2002/95. It can be mounted by blackplate or Din rail,also through the door of class II switchboard without downgrading switchboard insulation. The front of toggle offers IP40 protection, but when it is equiped extended rotary handle inside the switchboard, additional IP54 protection degree for extended rotary handle. This series have slots for electrical auxiliaries(MN/MX/OF/SD),depending on the type of trip unit if rotary handle installed. The fixed dimension is 140mm width.255mm height,110mm depth,
