Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Picture of Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
SKU:

K30F013UP

Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2

Old price: $449.35 INC GST
$350.49 INC GST
Available for Shipping : 24-Jul-2025
Complete cam switch, Harmony K1, K2, cam changeover switch, front mounting, plastic, 3 poles, 30degrees, 32A, 64x64mm, marked 1 2
Be the first to review this product
Manufacturer: Schneider Electric
Catalog
Instruction sheet
Environmental Disclosure
Declaration of conformity
Product Page Link
Product Data Sheet
This Harmony K30 complete cam switch/selector switch has 3 poles (3P). It also has a rating of 32A, a screw clamp mounting mode and a metallic color with black marking. It has "1 - 2" marking to indicate the position of the switch. This metal head complete cam switch/selector switch is designed to meet most industrial and process control application thanks to a compact size, an easy integration with 16mm and 22mm diameter units and has several selection functions. It has a 60 degree between its switching positions.

Products specifications

Attribute name Attribute value
Main
Off position without Off position
Return without
Cam switch head type with front plate 64 x 64 mm
Switching positions right: 30°, left: 330°
Type of operator black handle
IP degree of protection IP40 conforming to IEC 60529
Range of product Harmony K
Rotary handle padlocking without
Poles description 3P
Mounting location front
Component name K30
Cam switch function changeover switch
[Ith] conventional free air thermal current 32 A
Product or component type complete cam switch
Presentation of legend with metallic legend, 1 - 2 black marking
Fixing mode 4 holes
Complementary
Compatibility code K30F
Mechanical durability 300000 cycles
Contact operation slow-break
Tightening torque 1.2 N.m
Positive opening with
Electrical connection captive screw clamp terminals solid, clamping capacity: 2 x 6 mm², captive screw clamp terminals flexible, clamping capacity: 2 x 4 mm²
CAD overall height 64 mm
CAD overall depth 106 mm
CAD overall width 64 mm
Switching capacity in mA 6500 mA DC at 330 V 3 contact(s) for resistive load (T = 1 ms), 6500 mA DC at 220 V 2 contact(s) for resistive load (T = 1 ms), 6500 mA DC at 110 V 1 contact(s) for resistive load (T = 1 ms), 400 mA DC at 660 V 2 contact(s) for resistive load (T = 1 ms), 400 mA DC at 440 V 1 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 95 V 2 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 70 V 3 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 70 V 3 contact(s) for inductive load (T = 50 ms), 32000 mA DC at 48 V 2 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 48 V 2 contact(s) for inductive load (T = 50 ms), 32000 mA DC at 48 V 1 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 24 V 1 contact(s) for resistive load (T = 1 ms), 32000 mA DC at 24 V 1 contact(s) for inductive load (T = 50 ms), 32000 mA DC at 140 V 3 contact(s) for resistive load (T = 1 ms), 3200 mA DC at 330 V 3 contact(s) for inductive load (T = 50 ms), 3200 mA DC at 220 V 2 contact(s) for inductive load (T = 50 ms), 3200 mA DC at 110 V 1 contact(s) for inductive load (T = 50 ms), 25000 mA DC at 90 V 3 contact(s) for inductive load (T = 50 ms), 25000 mA DC at 60 V 2 contact(s) for inductive load (T = 50 ms), 25000 mA DC at 30 V 1 contact(s) for inductive load (T = 50 ms), 23000 mA DC at 60 V 1 contact(s) for resistive load (T = 1 ms), 23000 mA DC at 180 V 3 contact(s) for resistive load (T = 1 ms), 23000 mA DC at 120 V 2 contact(s) for resistive load (T = 1 ms), 16000 mA DC at 95 V 2 contact(s) for inductive load (T = 50 ms), 16000 mA DC at 48 V 1 contact(s) for inductive load (T = 50 ms), 16000 mA DC at 140 V 3 contact(s) for inductive load (T = 50 ms), 1200 mA DC at 660 V 3 contact(s) for resistive load (T = 1 ms), 1200 mA DC at 440 V 2 contact(s) for resistive load (T = 1 ms), 1200 mA DC at 220 V 1 contact(s) for resistive load (T = 1 ms), 11000 mA DC at 60 V 1 contact(s) for inductive load (T = 50 ms), 11000 mA DC at 180 V 3 contact(s) for inductive load (T = 50 ms), 11000 mA DC at 120 V 2 contact(s) for inductive load (T = 50 ms)
[Ui] rated insulation voltage 690 V (pollution degree 3) conforming to IEC 60947-1
Short-circuit current 5000 A
Switching angle 30 °
[Uimp] rated impulse withstand voltage 6 kV conforming to IEC 947-1, 6 kV conforming to EN 947-1
Net weight 0.425 kg
Short-circuit protection 50 A cartridge fuse, type gG
Environment
Protective treatment TC
Ambient air temperature for storage -40-70 °C
Ambient air temperature for operation -25-55 °C
Overvoltage category class II conforming to NF C 20-030, class II conforming to IEC 60536
Standards IEC 60947-3
Product certifications cULus 480 V 20 hp 3 phases, cULus 240 V 5 hp 3 phases, cULus 240 V 5 hp 1 phase, cULus 120 V 2 hp 1 phase
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 7.2 cm
Package 1 Width 7.2 cm
Package 1 Length 36.4 cm
Package 1 Weight 271.0 g
Unit Type of Package 2 2
Number of Units in Package 2 30
Package 2 Height 30.0 cm
Package 2 Width 30.0 cm
Package 2 Length 40.0 cm
Package 2 Weight 8.843 kg
