SKU:

HED5VSX

Duct Humidity Sensor: Economy, 5% Accuracy, 0-5VDC/0-10VDC Output

$315.62 INC GST

Qty:

Available for Shipping : 08-Oct-2025

Duct Humidity Sensor: Economy, 5% Accuracy, 0-5VDC/0-10VDC Output

Manufacturer: Veris Industries

Catalog

Product Page Link

Product Data Sheet

Duct Humidity Sensor: Economy, 5% Accuracy, 0-5VDC/0-10VDC Output

Attribute name	Attribute value
Main
Probe length	155 mm
Device application	duct
Depth	53 mm
Colour	cloud white
Width	82 mm
Sensor type	thin-film capacitive humidity
Response time	110 s (to 90 % change at 20 °C)
Location	plant room
Humidity measurement drift	≤1 % annually
Product or component type	sensor
Type of measurement	humidity
Mounting support	duct
Range of product	HED
Calibration certificate	humidity: none
Ambient air temperature for operation	-40-50 °C
Height	123 mm
Humidity measurement resolution	0.1 % RH
[Us] rated supply voltage	12...30 V DC, 24 V AC
Complementary
Diameter	25.4 mm probe:
Material	ABS thermoplastic: enclosure
Connections - terminals	screw terminal (AWG 24...AWG 14)
Output type	analog 0...10 V DC, analog 0...5 V DC

Feature level	economy
Setpoint	No
With override	No
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Weight	227.27 g
