SKU:

GV3P736

Motor circuit breaker,TeSys Deca frame 3,3P,62-73A,thermal magnetic,lugs terminals

Old price: $846.89 INC GST

Price: $533.54 INC GST

Qty:

Available for Shipping : 19-Aug-2025

Product Selector

Motor circuit breaker,TeSys Deca frame 3,3P,62-73A,thermal magnetic,lugs terminals

New modern look & feel of all machines

Wide range of GVs: Magnetic, thermal magnetic, different sizes (GV2,GV3,GV4)

Easier to install and operate with multi-standard screws

Safe and long-lasting power connection with EverLink terminals

Digital customer experience for technical documents

Maintenance guide via EcoStruxureTM Facility Expect

Be the first to review this product

Manufacturer: Schneider Electric

Instruction sheet

User guide

Circularity Profile

Environmental Disclosure

Product Page Link

Product Data Sheet

TeSys GV motor circuit breaker, 3 poles (3P), 73A/690V, for 3-phase motor applications 37kW@400V. It provides a thermal-magnetic protection with a thermal setting range 62-73A, magnetic tripping at 15xIn, high breaking capacity Icu 50kA@400V. Connection by bars or lugs. Start-stop control by rotary knob guaranteed for 20 000 cycles AC-3. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine, ATEX), Green Premium compliant (RoHS/REACh).

Products specifications

Attribute name	Attribute value
Main
Device short name	GV3P
Device application	motor protection
Range	TeSys Deca
Range of product	TeSys GV3
Trip unit technology	thermal-magnetic
Product name	TeSys Deca, TeSys GV3
Product or component type	motor circuit breaker
Complementary
Colour	dark grey
Connection pitch	17.5 mm without spreaders
Compatibility code	GV3P
Mechanical durability	50000 cycles
Tightening torque	6 N.m - on lugs-ring terminals
Suitability for isolation	yes conforming to IEC 60947-1
Breaking capacity	6 kA Icu at 690 V AC 50/60 Hz, 12 kA Icu at 500 V AC 50/60 Hz, 50 kA Icu at 440 V AC 50/60 Hz, 50 kA Icu at 400/415 V AC 50/60 Hz, 65 kA Icu at 230/240 V AC 50/60 Hz
Electrical durability	20000 cycles for AC-3 at 415 V In
Power dissipation per pole	8 W
Control type	rotary handle
[Ics] rated service short-circuit breaking capacity	50 % at 690 V AC 50/60 Hz, 50 % at 500 V AC 50/60 Hz, 60 % at 440 V AC 50/60 Hz, 60 % at 400/415 V AC 50/60 Hz, 100 % at 230/240 V AC 50/60 Hz
Fixing mode	panel: screwed (with 3 x M4 screws), 35 mm symmetrical DIN rail: clipped
Maximum operating rate	25 cyc/h
Magnetic tripping current	1120-1120 A
Phase failure sensitivity	yes conforming to IEC 60947-4-1
Height	132 mm
Network frequency	50/60 Hz
Depth	136 mm
Width	55 mm
Poles description	3P
Direct connector	without
Thermal protection adjustment range	62-73 A conforming to IEC 60947-4-1
[Ui] rated insulation voltage	690 V AC 50/60 Hz conforming to IEC 60947-2
[Uimp] rated impulse withstand voltage	6 kV conforming to IEC 60947-2
Net weight	0.96 kg
Utilisation category	AC-3 conforming to IEC 60947-4-1
Motor power kW	55-55 kW at 690 V AC 50/60 Hz, 45-45 kW at 500 V AC 50/60 Hz, 37-37 kW at 400/415 V AC 50/60 Hz
[Ith] conventional free air thermal current	73 A conforming to IEC 60947-4-1
Network type	AC
Rated duty	continuous conforming to IEC 60947-4-1
[Ue] rated operational voltage	690 V AC 50/60 Hz
[In] rated current	73 A
Environment
Fire resistance	960 °C conforming to IEC 60695-2-11
IP degree of protection	IP20 conforming to IEC 60529
Ambient air temperature for storage	-40-80 °C
Climatic withstand	conforming to IACS E10
Ambient air temperature for operation	-20-60 °C
Mechanical robustness	vibrations: 4 Gn, 5...300 Hz, shocks: 30 Gn for 11 ms contactor closed, shocks: 5 Gn for 11 ms contactor open
IK degree of protection	IK09 enclosure
Operating altitude	3000 m
Standards	CSA C22.2 No 60947-4-1, UL 60947-4-1, EN/IEC 60947-4-1, EN/IEC 60947-2
Product certifications	UKCA, DNV-GL, ABS, BV, LROS (Lloyds register of shipping), ATEX, EAC, CSA, UL, CCC
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	15.8 cm
Package 1 Width	6.5 cm
Package 1 Length	14.6 cm
Package 1 Weight	1.016 kg
