SKU:

AZ5CE007D

Cable ends, Linergy TR cable ends, single conductor, white, 0.75 mm², for insulated, medium size, 5 sets of 200

Old price: $0.23 INC GST

Price: $0.21 INC GST

Qty:

Available for Shipping : 12-Aug-2025

Cable ends, Linergy TR cable ends, single conductor, white, 0.75 mm², for insulated, medium size, 5 sets of 200

Manufacturer: Schneider Electric

Declaration of conformity

Circularity Profile

Catalog

Environmental Disclosure

Product Page Link

Product Data Sheet

Attribute name	Attribute value
Main
Quantity per set	5 sets of 200
Cable end size	medium
Cable cross section	0.75-0.75 mm²
Type of packing	dispenser pack
Product or component type	cable end
Standards	DIN 46228-4
Range of product	Linergy
Complementary
CAD overall depth	14 mm
CAD overall width	3 mm
Tube diameter	1.5 mm
Additional information	without marker tag holder
Tube material	copper conforming to ISO 1337
Bezel material	halogen-free plastic
Colour	grey
AWG gauge	AWG 20
CAD overall height	3 mm
Net weight	0.15 kg
Length	14 mm
Cable end type	single conductor
Number of cables	1
Bezel size	Ø 3.3 mm
Tube length	8 mm
Environment
Ambient air temperature for operation	-20-105 °C
Product certifications	UL
Packing Units
Unit Type of Package 1	1
Number of Units in Package 1	1
Package 1 Height	0.400 cm
Package 1 Width	0.400 cm
Package 1 Length	1.400 cm
Package 1 Weight	0.100 g
Unit Type of Package 2	2
Number of Units in Package 2	1000
Package 2 Height	13.000 cm
Package 2 Width	7.000 cm
Package 2 Length	12.600 cm
Package 2 Weight	138.000 g
Unit Type of Package 3	3
Number of Units in Package 3	5000
Package 3 Height	15.000 cm
Package 3 Width	15.000 cm
Package 3 Length	40.000 cm
Package 3 Weight	914.000 g
