Picture of Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 110...120V
SKU:

9001SKT1

Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 110...120V

Old price: $364.65 INC GST
$284.43 INC GST
Available for Shipping : 07-Sep-2025
Push-to-test pilot light head, Harmony 9001SK, plastic, without cap, 30mm, 110...120V
Be the first to review this product
Manufacturer: Schneider Electric
Declaration of conformity
CAD
Instruction sheet
Product environmental
End of life manual
Product Page Link
Product Data Sheet
This pilot light is part of the range of control and signaling units, Harmony 9001SK diameter 30mm plastic. It has a double insulated bezel and is delivered with push to test operator. It is supplied via internal transformer with 110V to 120V AC. Thanks to its double insulated bezel it is adapted for applications requiring a high resistance to corrosion. It is easily installed into a standard 30mm diameter panel cut-outs. The 30 mm Harmony range offers a large choice of robust and reliable products to meet a great number of applications in heavy industries such as petrochemy, metallurgy, mining oil and gas wastewater treatment, automobile manufacturing. It is UL listed and CSA certified, CE declaration of conformity and RoHS compliant.

Products specifications

Attribute name Attribute value
Main
Product or component type head for push-to-test pilot light
Light block supply via transformer 120 V AC 50/60 Hz, via transformer 110 V AC 50/60 Hz
Range of product Harmony 9001SK
Complementary
Bulb base BA 9s
Supply frequency 50...60 Hz
Bezel material plastic
Contacts type and composition 1 C/O
Size 30 mm
Cap/operator or lens colour without cap
Shape of signaling unit head round
Operating mode push-to-test
Light block supply via integral transformer
Mounting diameter 30 mm
Light source incandescent bulb
[Us] rated supply voltage 110...120 V
Environment
Protective treatment TC
IP degree of protection IP66
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.080 cm
Package 1 Width 5.588 cm
Package 1 Length 11.430 cm
Package 1 Weight 204.100 g
Unit Type of Package 2 2
Number of Units in Package 2 14
Package 2 Height 15 cm
Package 2 Width 15 cm
Package 2 Length 40 cm
Package 2 Weight 3.057 kg
Unit Type of Package 3 3
Number of Units in Package 3 448
Package 3 Height 75.000 cm
Package 3 Width 80.000 cm
Package 3 Length 60.000 cm
Package 3 Weight 105.837 kg
