Picture of Modicon Momentum - high speed counter module base - 6 I / 4 O
SKU:

170AEC92000

Modicon Momentum - high speed counter module base - 6 I / 4 O

$4,002.46 INC GST
Available for Shipping : 12-Aug-2025
Modicon Momentum - high speed counter module base - 6 I / 4 O
Be the first to review this product
Manufacturer: Schneider Electric
Circularity Profile
Environmental Disclosure
Instruction sheet
Declaration of conformity
User guide
Product Page Link
Product Data Sheet
This counter module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This high speed counter module base has 2 groups of 3 discrete inputs and 2 groups of 2 discrete outputs with positive discrete input logic. It is a module with discrete input voltage ranges from -3V DC to 30V DC, 24V DC and discrete output voltage of 24V. It is furnished with 2 removable terminal blocks for electrical connection. It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Products specifications

Attribute name Attribute value
Main
Number of counter 2
Range of product Modicon Momentum automation platform
Group of channels 2 groups of 2 discrete outputs, 2 groups of 3 discrete inputs
Discrete input number 6
Discrete output number 4
Product or component type high speed counter module base
Complementary
Voltage state 1 guaranteed >= 11 V
Counting frequency 200 kHz differential, 10 kHz single ended
Input overvoltage protection 45-45 V 10 s
Discrete input logic positive
Counting input type incremental up, down, quadrature, absolute SSI up, down with 4 sub-modes
Counting input voltage 5 V differential, 24 V single ended
Current state 1 guaranteed >= 2.5 mA
Discrete output voltage 24 V
Discrete output current 0.5 A per point, 2 A per module, 1 A per counter
Marking CE
Discrete input voltage 24 V DC, - 3...30 V DC
Discrete output logic positive
Counter configuration via comm adapter
Maximum leakage current 1 mA DC 24 V
Counter inputs resolution 24 bits + sign
Voltage state 0 guaranteed <= 5 V
Net weight 0.21 kg
Response time 3 ms from state 1 to state 0 input circuit, 3 ms from state 0 to state 1 input circuit, < 0.1 ms from state 1 to state 0 output circuit, < 0.1 ms from state 0 to state 1 output circuit
Surge current 5 A 1 ms
Current state 0 guaranteed <= 1.2 mA
Current consumption 280 mA at 24 V DC
Maximum voltage drop <0.5 V 0.5 A at state on
Electrical connection 2 connectors for removable terminal blocks
Environment
Protective treatment TC
Resistance to electrostatic discharge 8 kV on air conforming to IEC 801-2, 4 kV contact conforming to IEC 801-2
Relative humidity 95-95 % without condensation
Ambient air temperature for storage -40-85 °C
Resistance to electromagnetic fields 10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation 0-60 °C
Operating altitude <= 5000 m
Product certifications CSA, UL
Packing Units
Unit Type of Package 1 1
Number of Units in Package 1 1
Package 1 Height 5.800 cm
Package 1 Width 18.000 cm
Package 1 Length 26.200 cm
Package 1 Weight 356.000 g
Unit Type of Package 2 2
Number of Units in Package 2 8
Package 2 Height 30.000 cm
Package 2 Width 30.000 cm
Package 2 Length 40.000 cm
Package 2 Weight 3.336 kg
